Badger Fire Protection ABC Specifications
|
|
|||||||||
MODEL NO. |
250MB-1 |
5MB-7H* |
5MB7HB |
5MB-6H* |
5MB-6HB |
10MB-3H |
10MB-4H |
10MB-5H |
20MB-3H |
|---|---|---|---|---|---|---|---|---|---|
NOMINAL CAPACITY LBS. (KG.) |
2 1/2 (1.13) |
4 (1.81) |
4 (1.81) |
5 (2.27) |
5 (2.27) |
10 (4.54) |
10 (4-54) |
10 (4.54) |
20 (9.07) |
U/L RATING |
1A-10B:C |
2A-10B:C |
2A-10B:C |
3A-40B:C |
3A-40B:C |
3A40B:C |
4A-60B:C |
4A-60B:C |
20A-120B:C |
AGENT |
ABC |
ABC |
ABC |
ABC |
ABC |
ABC |
ABC |
ABC |
ABC |
ITEM PART NUMBER |
18412 |
21154 |
21161 |
21026 |
21032 |
19567 |
19386 |
21397 |
21380 |
VALVE MATERIAL |
ALUM. |
ALUM. |
ALUM. |
ALUM |
ALUM. |
ALUM. |
ALUM. |
BRASS |
BRASS |
SHELL MATERIAL |
STEEL |
STEEL |
STEEL |
STEEL |
STEEL |
STEEL |
STEEL |
STEEL |
STEEL |
PACKAGE QUANTITIES |
6 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
SHIPPING WT. LBS. (KG.) |
36# (16.3) |
9# (4.1) |
9# (4.1) |
10# (4.5) |
10# (4.5) |
19# (8.6) |
18# (8.1) |
19# (8.6) |
38# (17.2) |
OPERATING PRESSURE |
195 PSI |
195 PSI |
195 PSI |
195 PSI |
195 PSI |
195 PSI |
195 PSI |
195 PSI |
195 PSI |
TEMP RANGE (F) |
-401 TO 1201 |
-401 TO 1201 |
-401 TO 1201 |
-401 TO 1201 |
-401 TO 1201 |
-401 TO 1201 |
-401 TO 1201 |
-401 TO 1201 |
-401 TO 1201 |
DISCHARGE TIME (SEC.) |
9.5 |
14.0 |
14.0 |
14.0 |
14.0 |
18.0 |
18.0 |
18.0 |
28.0 |
RANGE FEET (METERS) |
10-15 (3.1-4.6) |
12-18 (3.7-5.5) |
12-18 (3.7-5.5) |
12-18 (3.7-5.5) |
12-18 (3.7-5.5) |
12-18 (3.7-5.5) |
16-20 (4.9-6.1) |
16-20 (4.9-6.1) |
16-20 (4.9-6.1) |
UNIT HEIGHT IN.(CM.) |
14 N (37.78) |
15 ¼ (38.7) |
15 ¼ (38.7) |
15 ¼ (38.7) |
15 ¼ (38.7) |
16 5/8 (42.32) |
24 ½ (62.25) |
16 5/8 (42.32) |
24 ½ (62.25) |
UNIT WIDTH IN.(CM.) |
5 ½ (13.97) |
7 ¼ (18.41) |
7 ¼ (18.41) |
7 ¼ (18.41) |
7 ¼ (18.41) |
9 ¾ (24.76) |
6 ½ (16.50) |
6 ½ (16.50) |
7 ¾ (19.58) |
SHELL DIAMETER IN.(CM.) |
3 (7.62) |
4 ¼ (10.8) |
4 ¼ (10.8) |
4 ¼ (10.8) |
4 ¼ (10.8) |
6 (15.241) |
5 3/32 (12.94) |
5 3/32 (12.94) |
6 5/8(16.83 |
USCG APPROVAL |
YES |
YES |
YES |
YES |
YES |
YES |
YES |
YES |
YES |
USCG BRACKET |
MB-250 (INCL.) |
MB-5 (OPT.) |
MB-5 (INCL.) |
MB-5 (OPT.) |
MB-5 (INCL.) |
MB-10DC (OPT.) |
UB-10 (OPT.) |
UB-10 (OPT.) |
UB-20 (OPT.) |
* Model Not Pictured
