Badger Fire Protection Cartridge (Dry Chem) Specifications


MODEL NO.

10MBC

20MBC

30MBC

10HBC*

20HBC*

10KBC*

20KBC*

30KBC*

CO2

N2

CO2

N2

CO2

N2

CO2

N2

CO2

N2

CO2

N2

CO2

N2

CO2

N2

Nominal Capacity Lbs. (Kg.)

10 (4.54)

20 (9.07)

25 (11.3)

12 (5.44)

22 (9.98)

9 (4.08)

18 (8.16)

27 (12.3)

U/L Rating

4A-60B:C

20A-80B:C

20A-120B:C

60B:C

80B:C

60B:C

80B:C

120B:C

Agent

MULTI
PURPOSE

MULTI
PURPOSE

MULTI
PURPOSE

REGULAR

REGULAR

PURPLE K

PURPLE K

PURPLE K

Item Part Number

17246

17247

17254

17255

17367

17407

17250

17251

17258

17259

17440

17449

17455

17462

17387

17415

Valve Material

ALUM.

ALUM.

ALUM.

ALUM.

ALUM.

ALUM.

ALUM.

ALUM.

Shell Material

STEEL

STEEL

STEEL

STEEL

STEEL

STEEL

STEEL

STEEL

Package Quantities

1

1

1

1

1

1

1

1

Shipping Wt. Lbs. (Kg.)

21 (9.53)

42 (19.05)

51 (21.13)

23 (10.43)

44 (19.96)

20 (9.07)

40 (18.14)

53 (24.04)

Operating Pressure

170

170

170

170

170

170

170

170

Temp Range (F)

-40 TO 120

65 TO 120

-40 TO 120

65 TO 120

-40 TO 120

65 TO 120

-40 TO 120

65 TO 120

-40 TO 120

65 TO 120

-40 TO 120

65 TO 120

-40 TO 120

65 TO 120

-40 TO 120

65 TO 120

Discharge Time (Sec.)

19

22

32

19

23

18

22

28

Range Feet (Meters)

15-20
(4.6-6.1)

15-20
(4.6-6.1)

15-20
(4.6-6.1)

15-20
(4.6-6.1)

15-20
(4.6-6.1)

15-20
(4.6-6.1)

15-20
(4.6-6.1)

15-20
(4.6-6.1)

Unit Height In. (Cm.)

18-1/2
(47)

21-1/2
(54.6)

26-5/16
(66.8)

18-1/2
(47)

21-1/2
(54.6)

18-1/2
(47)

21-1/2
(54.6)

26-5/16
(66.8)

Unit Width In. (Cm.)

9
(22.9)

10-3/4
(27.3)

10-3/4
(27.3)

9
(22.9)

10-3/4
(27.3)

9 (22.9)

10-3/4
(27.3)

10-3/4
(27.3)

Shell Diameter In. (Cm.)

5-5/32
(12.94)

6-5/8
(16.80)

6-5/8
(16.80)

5-5/32
(12.94)

6-5/8
(16.80)

5-5/32
(12.94)

6-5/8
(16.80)

6-5/8
(16.80)

USCG Approval

YES

YES

YES

YES

YES

YES

YES

YES

USCG Bracket

CB-10

CB-20

CB-30

CB-10

CB-20

CB-10

CB-20

CB-30

* Model Not Pictured
